2.50mm Female Pluggable terminal block Right Angle Pin

Electrical:
Rated voltage: 150V
Rated current: 5A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1500V/1Min

Material:
Pin header: Brass,Sn plated
Housing: PA66, UL94V-0

Mechanical:
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.

KLS2-EDR-2.50.pdf
