- Product Details
Electrical:
Rated voltage: 300V
Rated current: 10A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC2000V/1Min
Wire range: 26~14AWG 2.5MM²
Material:
Housing: PA66 , UL94V-0
Pin header: Brass, Tin plated
Wire guard: Stainless steel
Mechanical:
Temp. Range: -40 ° C ~ + 105 ° C
Soldering: 250° C±5° C for 5S
Strip length: 8~9mm
