Material:
Housing: PA66, UL94V-0
Contactor: Copper alloy
Contactive Coating: Sn plated

Electrical:
Rated voltage: 600V
Rated current: 40A
Withstand voltage: AC2000V/1min
Wire Range:8~24AWG

Mechanical:
Pitch/Poles: 7.50/01~18
Temp. Range: -40ºC~+105ºC
Strip length: -15mm
Pin Dimensions: 1.7×0.8
PCB Hole Dimensions: φ2.1

KLS2-262V-7.50.pdf
