ELECTRICAL
1.Rating: 50mA 12V DC
2.Contact Resistance : 100mΩ Max
3.Insulation Resistance: 100MΩ Min
4.Dielectric Strength : 250V AC for 1min
5.Electrically Life:30000cycles
6.Environment temperature:-30ºC~+80ºC
7.Operating Force: 160/250(±30gf)
8.Seal temperature:260ºC~ 280ºC

Materials:
A. cards: 0.3 brass, silver
B. Base: 6T, black
C. Reed: Imported phosphor coated silver
D. button:6T, black
E. Cover: 0.3 brass, copper, tin

KLS7-TS6661.pdf
