Material
Housing:Thermoplastics,UL94V-0,PTB/LCP,Black/White.
Contact:Copper Alloy.
Shell:Copper Alloy /Steel.Nickel plated/Tin-Lead plated.

Electrical:
Voltage Current Rating:1.5AMP.30V AC.
Insulation Resistance:1000MΩ Min.
Contact Resistance:30mΩ Max.
Dielectric Withstanding Voltage:500 V AC.
Temperature Range:-35°C TO +85°C.

Mechanical:
Mating Force:3.5KG Max.
Unmating Force:1.0KG Min.

KLS1-229-5MA.pdf
