Material:
Housing: PA66 , UL94V-0
Pin header: Brass, Tin plated
Wire guard: Stainless steel

Electrical:
Rated voltage: 300V
Rated current: 10A
Wire range: 26~14AWG 2.5mm²
Contact Resistance: 20 m Ω
Insulation resistance: 500MΩ/DC500V
Withstand voltage: AC2000V / 1 min

Mechanical:
Temp. Range: -40 ° C ~ + 105 ° C
Soldering: 250° C±5° C for 5S
Strip length: 5~6mm

KLS2-245-5.00.pdf
