Material:
Shrapnel: Stainless steel
Pin header: Brass , Tin plated
Housing: PA66 , UL94V-0

Electrical:
Rated voltage: 300V
Rated current: 10A
Wire range: 26~16AWG 1.5mm²
Contact Resistance: 20 m Ω
Insulation resistance: 500MΩ/DC500V
Withstand voltage: AC2000V / 1 min

Mechanical:
Temp. Range: -40 ° C ~ + 105 ° C
Soldering: 250° C±5° C for 5S
Strip length: 8~9mm

KLS2-211V-5.00.pdf
