Electrical :
Rated voltage: 300V
Rated current: 16A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC2000V/1Min
Wire range: 22-12AWG 2.5mm²

Material
Screws: M2.5 steel Zinc plated
Contact: Brass,Ni Plated
Pin header: Brass, Tin plated
Housing: PA66, UL94V-0

Mechanical
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 0.4Nm (3.54lb.in)
Strip length: 6-7mm

KLS2-128-5.00.pdf
