Material
Screw:        M2.5, Steel,Zn plated
Shrapnel:     stainless steel
Pin header:   Brass, Tin plated
Housing:       LCP, UL94V-0
Electrical
Rated voltage:  300V
Rated current:  16A
Wire range:      22~14AWG  1.5mm²
Contact Resistance: 20 m Ω
Insulation resistance:  1MΩ
Withstand voltage:      AC1600V / 1 min
Mechanical
Temp. Range:   -40 ° C ~ + 115 ° C
Soldering:         265 ° C   5Sec.  Max.
Torque:            0.4 N.m (3.5Lb. in)
Strip length:     5~6 mm

KLS2-THR301-5.00.pdf
