Electrical：
Rated voltage:300V
Rated current:12A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1600V/1Min
Wire range:26-14AWG1.5mm²

Material：
Screws: M2.5steel Zinc plated
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0

Mechanical：
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque:0.4Nm (10.6lb.in)
Strip length:5~6mm

KLS2-127A-5.00.pdf
