5.00mm Pitch Pluggable Terminal Block / 5.08mm Pitch Pluggable Terminal Block

Electrical:
Rated voltage: 300V
Rated current: 15A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding Voltage: AC1500V/1Min

Material:
Housing: Pa66, UL94V-0
Screws: M2.5,steel,Zinc plated
Contact :Phosphor Bronze

Mechanical:
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec
Wire range: 28-12AWG 2.5mm²
Torque:0.4Nm (3.6Lb. in)
Strip length: 7-8 mm

KLS2-EDKDM-500/KLS2-EDKDM-5.08.pdf
