Electrical:
1.Rating:50mA 12V DC
2.Contact Resistance:100mΩ Max.
3.Insulation Resistance:100MΩ Min,100V DC
4.Dielectric voltage proof:250V AC for 1min
5.Electrically Life:30000 cycles Min.
6.Operating Force:250±50gf
7.Environment temperature:-30ºC~+70ºC

Materials:
1.Cards: Phosphor ,Silver
2.Pedestal:FR52,Black
3.Shrapnel:Stainless steel
4.Dust Film:0.05
5.Push button:FR52,Black
6.Cover:Phosphor 0.15

KLS7-TS3501.pdf
