Electrical:
1.Rating:50mA 12V DC
2.Contact Resistance:100mΩ Max.
3.Insulation Resistance:100MΩ Min,100V DC
4.Dielectric voltage proof:250V AC for 1min
5.Electrically Life:100000 cycles Min.
6.Operating Force:250±50gf
7.Environment temperature:-30ºC~+80ºC

Materials:
A.Cards: Phosphor 0.12,Plated nickel silver
B.Pedestal:LCP,White
C.Shrapnel:Stainless steel
D.Push button:LCP,White
E.Cover:Stainless steel 0.2

KLS7-TS3401.pdf
