Specifications
Antenna
Frequency: GPS L1/L2/L5
GLONASS G1/G2
COMPASS B1/B2/B3
Galileo E1/E2/E5a/E5b/E6
Polarization: RHCP
Axial Ratio: ≤3dB
V.S.W.R: ≤2.0
Peak Gain: ≥7dBi
Impedance: 50Ω
Phase Center Error: ±1mm
Horizontal coverage angle: 360°

LNA
Gain: 40±2dB
Noise Figure: ≤2
Passband fluctuation: ±2dB
Supply Voltage: 3~12V DC
Current Consumption: ≤45mA
V.S.W.R: ≤2.0

Mechanical
Connector: TNC-K

Environmental
Operating Temperature: -40℃~+85℃
Relative Humidity: Up to 95%
Ingress Protection: IP67 (exclude Air vent in screw hole)
Environmentally Friendly: ROHS Comp
