It is characterized by stable technical performance, high efficiency, small volume, high protection grade and high seismic grade.
Adopt liquid cooling way, heat dissipation speed is fast, dustproof, noise is small
Application:
New energy vehicle
Industrial control products
Energy storage power station
IDC Data Center
Product size: 411*401*136mm (without plug-ins)
Product weight: 15KG
Input voltage: 100-300VDC
Output voltage: 400-700VDC
Maximum output current: 70A
Rated output power: 15/36KW
Full load efficiency: 96%
Protection level: IP67
Communication port: CAN2.0
