Technical parameters:
Rated voltage:DC 30V
Rated current: 0.5A
Contact resistance:0.03Ω max
Insulation resistance:100MΩ (DC250V)
Withstand Voltage:500VAC
Insertion Force :3-20N
Life:5000 times

Material:
1、Housing:PBT
2、Contact Foot：Phosphor bronze, Ag-Plating
3、Spring Piece:Phosphor bronze, Ag-Plating
4、Curve Piece:Brass, Ag-Plating
5、Contact Foot:Phosphor bronze, Ag-Plating
6、CAP:H59 Brass, Ni-Plating

KLS1-TG3-004.pdf
