3.50mm & 3.81mm Female Pluggable terminal block With Fixed hole
- Product Details
3.5mm Pitch Pluggable Terminal Block / 3.81mm Pitch Pluggable Terminal Block
Electrical :
Rated voltage: 300V
Rated current: 8A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding Voltage: AC2000V/1Min
Material:
Pin header: Brass, Tin plated
Housing: PA66, UL94V-0
Mechanical:
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec
