3.50mm & 3.81mm Female Pluggable terminal block Straight Pin

Inquiry

Electrical:

Rated voltage: 300V

Rated current: 8A

Contact resistance: 20mΩ

Insulation resistance: 500MΩ/DC500V

Withstanding Voltage: AC1600V/1Min

Material:

Pin header: Brass, Sn plated
Housing: PA66, UL94V-0

Mechanical:

Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
