Electrical:
1.Rating:50mA 12V DC
2.Contact Resistance:100mΩ Max.
3.Insulation Resistance:100MΩ Min,100V DC
4.Dielectric voltage proof:250V AC for 1min
5.Electrically Life:100000 cycles Min.
6.Operating Force:250±50gf
7.Environment temperature:-30ºC~+80ºC

Materials:
1.Cards: Phosphor 0.12, Silver plated
2.Pedestal:LCP, Black
3.Shrapnel:Stainless steel
4.Push button:LCP,White
5.Cover:Phosphor 0.12

KLS7-TS3345.pdf
