ELECTRICAL
1.Rating: 50mA 12V DC
2.Contact Resistance : 100mΩ Max
3.Insulation Resistance: 100MΩ Min
4.Dielectric Strength : 250V AC for 1min
5.Electrically Life:100000cycles
6.Environment temperature:-30ºC~+80ºC
7.Operating Force: 160/250(±30gf)
8.Seal temperature:260ºC~ 280ºC

Materials:
A. cards: phosphor bronze 0.15, silver
B. Base: E1301
C. Reed: Imported steel impervious cover silver
D.Plastic cover:E1301
E. button: LCP, black
F. Cover: phosphor bronze 0.2, silvered

KLS7-TS2301.pdf
