Electrical Characteristics
Rated Power:                DC5V   5mA Max.
Output signal:               A \ B  2signals
Resolution:                  10 Pulses 360°
Phase difference:         0.08T  Min.
Sliding noise:                3mS   Max.
Contact Resistance:     1 Ω  Max.
Insulation resistance:  100MΩ Min. at DC 250V
Withstand voltage:      AC300V / 1 min

Mechanical
Total rotation angle:    360°
Click Torque:                30~150gf.cm Max
Push-pull Strength of Shaft:    8.0kgf Min.
Shaft wobble:               0.7xL/30mm  P-P max.  L-shaft length
Number of Detents(Click):      20 detents  Step angle:18°±2°
Shaft play in axial direction:  0.4mm Max.
shaft play in rotational wobble: 5° Max.
Rotational Life:            30000±200 cycles  per 100gf.cm Min.
Temp. Range:               -40 ° C ~ + 85 ° C
Soldering:                  250 ° C   5Sec.  Max.
