MATERAL
Insulator:    LCP,Black
Contact:      Phosphor Bronze,Contact Gold plated, Tin plated area
FITTING NAIL: STEEL,Tin plated.

ELECTRICAL
Current Rating:                    2A 12VDC
Dielectric Withstanding:     500V AC 1 min.
Insulation Resistance:       500MΩ Min.
Contact Resistance:          30mΩ Max.
Temperature range:           -40°C To +85°C

Packing:
1. Reel Packing

KLS1-PBC07.pdf
