Electrical :
Rated voltage: 300V
Rated current: 4A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/500V
Withstanding Voltage: AC2000V/1Min
Wire range: 28-20AWG  0.5mm²

Material:
Pin header: Phosphor bronze, Tin plated
Housing: PA66, UL94V-0

Mechanical
Temp. Range: -40ºC~+105ºC MAX
Soldering: +250ºC for 5 Sec.
Strip length: 9~10mm
