2.0mm Pitch ZIP Strip Socket Connector

  • Model: KLS1-108N
  • MOQ: 1000 PCS
  • Payment: L/C, D/A, D/P, T/T
  • Place_of_Origin China
  • Delivery_Time: 10 days
  • Product Details
  • PDF

2.0mm Pitch ZIP Strip Socket Connector

Order Information
KLS1-108N-XX
XX-No.of 28~40pin

Material:
Housing: 30% Glass filled PBT UL 94V-0
Contacts: Phosphor Bronze
Plating: Gold plated: 3u” over 50u” nickel
Tin plated: 100u” over 50u” nickel
Electrical Characteristics:
Current rating: 1AMP.
Insulator resistence: 5000MΩ min, at DC 500V
Contact resistence: 20mΩ max, at DC 100mA
Operating Temperature: -55°C~+105°C
Features:
Lever actuated zero insertion force mechanism
Socket easily disassembles for repair ability
