2.0mm Box Header Connector Height 6.35mm Molex 87831 87832 87833

  • Model: KLS1-202H
  • MOQ: 1000 PCS
  • Payment: L/C, D/A, D/P, T/T
  • Place_of_Origin China
  • Delivery_Time: 10 days
  • Product Details
  • PDF

2.0mm Box Header Connector Height 6.35mm Molex 87831 87832 87833

Order Information
KLS1-202H-XX-S-B-口
XX-No.of  06~64pin
S-Straight pin  R-Right Angle Pin   T-SMT Pin
B-Black  G-Gray   L-Blue
Material_NONE=PA6T   A=PBT  C=LCP

Material:
Housing: PA6T UL94V-0
Contacts: Brass
Plating:Gold 1u” over 50u” nickel
Electrical Characteristics:
Current Rating: 1.5 AMP
Contact Resistance: 20m Ohm max.
Insulator Resistance: 800M Ohm min.
Withstand voltage:400V AC/DC
Operating Temperature: -45ºC~+105ºC
