Electrical:
Rated voltage:300V
Rated current:52A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC2200V/1Min
Wire range:20-6AWG10mm²

Material:
Screws: M4steel Zinc plated
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0

Mechanical:
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 1.2Nm (10.6lb.in)
Strip length: 10mm

KLS2-151-12.7.pdf
