Electrical Specifications:
Insertion Loss: 1-100MHZ -1.0dB MAX
Return Loss: 1-30MHZ -16.0dB MIN
30-60MHZ -14.0dB MIN
60-80MHZ -10.0dB MIN
Cross Talk: 1-30MHZ -40.0dB MIN
30-60MHZ -35.0dB MIN
60-80MHZ -30.0dB MIN
CMR: 1M-100MHZ -35dB MIN .
Hi-Pot: 1500v AC 6S 1mA
OCL: 350uH MIN @ 100KHZ 100mV 8mA DC
Turn Ratio: 1CT : 1CT+/-3%
Contacts: 0.35mm thick phos bronze plated with 6u’ gold in contact area
Housing Material: PBT Black
Operating temperature range:-40 °C~+ 85°C

KLS12-TL173.pdf
