Electrical Specifications:
RoHS peak wave solder temperature rating 235℃
High performance for mximum EMI suppression
350uH minmum OCL with 8mA bias current

MECHANICAL:
JACK CAVITY CONFORMS TO FCC RULES AND
REGULATIONS,PART 68 SUBPART F.
INSERTION FORCE: 2 CONTACTS—-350g     4 CONTACTS—-500g
6 CONTACTS—-750g     8 CONTAC-S—-900g
10 CONTACTS—-1050g
RETENTION STRENGTH: 7.7Kgs BETWEEN JACK AND PLUG

DURABILUTY:
750 MATING CYCLES Mini

MATERIAL:
HOUSING: 1) GLASS FLLED PA66 (UL 94V-0)
2) GLASS FLLED PA46/LCP (UL 94V-0)
3) GLASS FILLED PBT UL 94V-0)
SPING WIRE: 1)0.2-0.45mm DIA PHOSPHOR BRONZE GOLD
PLATING OVER NICKE
2) 0.2-0.35mm THICKNESS PHOSPHOR BRONZE ALLOY
SELECTIVE GOLD PLATING OVER NICKEL
SHIELDING: 0.12-0.24mm THICKNESS COPPER ALLOY WITH TIN PLATED
GOLD PLATING: 3u” ,6u”，15u”, 30u” , 50u”
WORKING TEMPERATURE: -200700
TOLERANCES UNLESS 0THERWISE SPECFIED: 0~10+0.15.10~20+0.2. 20~40+0.25. 10~70+0.3>70+0.4

KLS12-TL138.pdf
