Electrical S pecifications:
RoHS peak wave solder temperature rating 235℃
High performance for maximum EMI suppression
350uH minmum OCL with 8mA bias current
PoE rating: 15W,350mA,48V (For PoE Products only)

MECHANICAL:
JACK CAVITY CONFORMS T0 FCC RULES AND
REGULATIONS,PART 68 SUBPART F.
INSERTION FORCE: 2 CONTACTS—-350g     4 CONTACTS–500
6 CONTACTS—-750g     8 CONTACTS—-900g
10 CONTACTS—- 1050g
RETENTION STRENGTH: 7.7Kgs BETWEEN JACK AND PLUG

DURABILUTY:
750 MATING CYCLES Mini

MATERIAL:
HOUSING: 1) GLASS FLLED PA66 (UL 94V-0)
2) GLASS FILLED PA46/LCP (UL 94V-0)
3) CLASS FILLED PBT (UL 94V-0)
SPRING WIRE: 1) 0.2-0.45mm DIA PHOSPHOR BRONZE GOLD
PLATING OVER NICKE
2) 0.2-0.35mm THICKNESS PHOSPHOR BRONZE ALLOY
SELECTIVE GOLD PLATING OVER NICKEL
SHIELDING: 0.12-0.24mm THICNESS COPPER ALLOY WITH TIN PLATED
GOLD PLAING: 3u” ,6u”，15u” , 30u” , 50u”
WORKING TEMPERATURE: -20℃~70℃
TOLERANCES UNLESS OTHERWISE SPECIFIED : 0~10±0.15、10~20±0.2、20~40±0.25、 10~70±0.3≥70±0.4
