ELECTRICAL:
RoHS peak wove solder temperature roting 235℃
High performance for maximum EMI suppression
350uH minmum OCL with 8mA bios current
PoE roting: 15W,350mA,48V (For PoE Products only)

MECHANICAL:
JACK CAMITY CONFORMS T0 FCC RULES AND
REGULATIONS,PART 68 SUBPART F.
INSERTION FORCE: 2 CONTACTS—-350q    4 CONTACTS—-500g
6 CONTACTS—-750g     8 CONTACTS—-900g
10 CONTACTS—-1050g
RETENTION STRENGTH: 7.7Kgs BETWEEN JACK AND PLUG

DURABLIY:
750 MATING CYCLES Mini

±MATERIAL:
HOUSING: 1) GLASS FLLED PA66 (UL 94V-0)
2) GLASS FLLED PA46/LCP (UL 94V-0)
3) CLASS FLLED PBT (UL 94V-0)
SPRING WRE: 1) 0.2-0.45mm DIA PHOSPHOR BRONZE GOLD
PLATING OVER NICKE
2) 0.2-0.35mm THICNESS PHOSPHOR BRONZE ALLOY
SELECTME GOLD PLATING OVER NICKEL

SHIELDING:
0.12-0.24mm THICNESS COPPER ALLOY WITH TIN PLATED
GOLD PLATING: 3u”，6″，15u” , 30u” , 50u”
WORKING TEMPERATURE: -20℃~70℃
TOLERANCES UNLESS 0OTHERWISE SPECFID : 0~10±0.15、10~20±0.2、20~40±0.25.
10~70±0.3>70±0.4

KLS12-TL133.pdf
