1- Center Contact: Brass,Gold-plated
2- Body-diecast: Brass,Gold-plated
3- Insulation: PTFE
4- Electrical
Impedance: 75 Ω
Frequency Range:0~10 GHz Max.
Voltage Rating: 250 volts
Withstand Voltage:750V
Insulation Resistance 10000 MΩ
V.S.W.R:＜1.3
Contact resistance:
Centre contact: 10 mΩ
Outer contact: 3 mΩ
6-Mechanical
Mating: Slide-On Push-Pull Threaded
7-Temp.range -40°C~85°C
