1- Center Contact: Brass,Gold-plated
2- Body-diecast:   Brass,Gold-plated
3- Insulation:     PTFE
4- Electrical
    Impedance: 75 Ω
    Frequency Range:0~10 GHz Max.
    Voltage Rating: 250 volts
    Withstand Voltage:750V
    Insulation Resistance 10000 MΩ
    V.S.W.R:＜1.3
    Contact resistance:
      Centre contact: 10 mΩ
      Outer contact:  3  mΩ
6-Mechanical
   Mating: Slide-On Push-Pull Threaded
7-Temp.range   -40°C~85°C
